Product Summary

The ZUS25 is a DC-DC converter.

Parametrics

ZUS25 specifications: (1)Input current: typ=2.03A; (2)Input efficiency: typ=82%; (3)Output voltage: 5V; (4)Output current: 4.0A; (5)Output line regulation: max=20mV; (6)Output load regulation: max=40mV; (7)Output ripple: max=80mVp-p; (8)Output ripple noise: max=120mVp-p; (9)Output drift: max=20mV; (10)Output start-up time: max=100ms(minimum input, lo=100%).

Features

ZUS25 electrical characteristic: (1)Max output wattage: 20.0W; (2)DC output voltage: 5V; current: 4.0A.
